APEX Pressure Reducing Valve 3.7 - FV3.7
$224.00
Quantity
APEX Pressure Reducing Valve 3.7 - FV3.7
Pressure compensated to give constant outlet pressure regardless of inlet pressure
Silicon rubber diaphragm and washer - no heat loop required
N.Z. forged, high quality, corrosion resistant DR brass body
Machined, assembled and 100% tested in NZ
One-piece forged brass fork with no water paths - no leaks!
Inlet: 15mm, 1/2" BSP (male) Outlet: 20mm, 3/4" BSP (male) Length: 138mm
Set pressures
FV3.7
Adjustable pressure range
FV3.7 - 15 to 100 kPa
Maximum Inlet Pressure: 2000 kPa
Maximum Inlet Temperature: Plastic Cap: 40°C
